Name: cross partition board micrometer carrier piece 75*25MM glass ruler diving rule graduated scale
Brand: Optry
SKU: 00065
Rating: 4.1 (83 reviews)

cross partition board micrometer carrier piece 75*25MM glass ruler diving rule graduated scale

An eyepiece micrometer is a circular glass slide with a 5mm length in the center of the slide cut into 50 equal parts, or a 10 mm length cut into 100 equal parts. When measuring, place it on the septum in the eyepiece (where it just overlaps with the intermediate image magnified by the objective) to measure the cellular image magnified by the microscope. Due to the different magnifications of different eyepieces and objective lens combinations, the actual length of each grid of the eyepiece micrometer is also different. Therefore, when measuring the size of microorganisms, the eyepiece micrometer must be calibrated with the stage micrometer placed on the stage first. Find the relative length represented by each cell of the eyepiece micrometer under a certain magnification. In the field of view of the microscope, the observed size of each cell of the eyepiece micrometer remains the same. Therefore, the larger the magnification of the eyepiece and the objective lens, the smaller the actual length indicated by each small grid of the eyepiece micrometer. This principle is the same as the field of view area, and the field of view area observed under the microscope is unchanged. When the eyepiece and objective multiples are small, the number of cells in the field of view is large, and the actual area represented by the field of view is large; when the eyepiece and objective lens are large, the number of cells in the field of view is small, and the actual area represented by the field of view is small
